FEATURES OF THE EVO STORE
LOCKABLE DRAWER
To keep accessories secure, include a lockable drawer. This can be fitted underneath the worktop on smooth ball bearing slides to ensure a safe and efficient use of the cart. The drawer measures 566mm in width by 254mm in length and includes a depth of 97mm.
PC HOLDER
A PC can be securely kept in place on the cart with this reliable PC holder. It can be mounted on either the left or right of the cart base with an option for the hand wheel to be replaced with a security fixing.
Suitable for a Small Form Factor (SFF) PC with dimensions of:
Max Width of 95mm
Max Depth of 295mm
Max Height 295mm
Min height of 275mm
STORAGE TRAY
This storage tray is height adjustable and can be used both with and without the cable tray (pictured) and in combination with our cabinet. There's an option for the hand wheel to be replaced with security fixings. The tray can be used with the cabinet beneath. Max load of 10kg.
Dimensions:
Length is 520mm Width is 225mm and depth is 70mm.
​
MONITOR ARMS
Both single and dual monitor posts available, both fully adjustable, VESA 75 & 100 compliant with a removable base clamp. Easily rotate between portrait and landscape with a 360° rotation around the post. Our monitor arms are available in a range of heights to suit your requirements.
​
We also offer laptop and tablet monitor arms.
CABLE TRAY
Securely stores power strips (2 x 4 way PDUs), small equipment, and cabling. It also includes an integrated cable chain for optimal cable management.
The rear cover is removable with thumb screws (option to use security fixings).
Dimensions are 467mm in height, 191mm in width and depth.
CORE FEATURES
All our carts will include the following features
01
Worktop
Our High-Pressure Laminate (HPL) worktops have a large work surface and an ergonomic curved design, as well as a rear handle and cable entry holes. The top includes rear accessory mounting holes and mounting points on the underside for accessories. Starting from a Max Loading rate of 20KG. Standard colour is Light Grey - other colours are available.
03
Base
Our bases to all the carts feature a curved ergonomic design for enhanced user accessibility and to ensure users can stand as close as possible to the cart. They’re made from heavy duty steel to endure the toughest of working environments and have a powder coated steel RAL 7021- other colours are available
02
Gas Strut
All our carts are height adjustable and can be altered using a gas strut. This super-efficient and simple mechanism will mean every cart ranges in height from 525mm to 815mm. Outer casing of strut is steel and powder coated Grey RAL9006 as standard (other RAL colours are available.)
04
Castors
All castors are braked, ensuring maximum control over the cart including wheel rotation and swivel. A smooth operation is assured with these ball bearing castors. Standard finish is in Grey, other colours are available.
